84 Degree Dies, 100mm | Press Brake Tooling

84° Dies, H=100mm, Amada Press Brake Tooling

Need specific tooling that’s not listed? Leave your contact details, and our experts will assist you with a customized technical solution, at no additional cost.

F 25.200 (300KN/m Max)
Length	Weight
500mm	4.5KG
300mm	2.7KG
200mm	1.8KG
100mm	0.9KG
550mm sectionalized	5.0KG

Inquiry

F 25.300 (250KN/m Max)
Length	Weight
500mm	4.5KG
300mm	2.7KG
200mm	1.8KG
100mm	0.9KG
550mm sectionalized	5.0KG

Inquiry

F 25.201 (1000KN/m Max)
Length	Weight
500mm	9.0KG
300mm	5.4KG
200mm	3.6KG
100mm	1.8KG
550mm sectionalized	9.9KG

Inquiry

F 25.202 (1000KN/m Max)
Length	Weight
500mm	9.0KG
300mm	5.4KG
200mm	3.6KG
100mm	1.8KG
550mm sectionalized	9.9KG

Inquiry

F 25.203 (1000KN/m Max)
Length	Weight
500mm	9.0KG
300mm	5.4KG
200mm	3.6KG
100mm	1.8KG
550mm sectionalized	9.9KG

Inquiry

F 25.204 (1000KN/m Max)
Length	Weight
500mm	10.5KG
300mm	6.3KG
200mm	4.2KG
100mm	2.1KG
550mm sectionalized	11.6KG

Inquiry

F 25.205 (1000KN/m Max)
Length	Weight
500mm	12.5KG
300mm	7.5KG
200mm	5.0KG
100mm	2.5KG
550mm sectionalized	13.8KG

Inquiry

F 25.206 (1000KN/m Max)
Length	Weight
500mm	12.5KG
300mm	7.5KG
200mm	5.0KG
100mm	2.5KG
550mm sectionalized	13.8KG

Inquiry

Reach out to us to learn more about our press brake tooling, designed for precision and efficiency.
