78 Degree Press Brake Punch | Metal Forming Tools

78° Punches/top-tools, Amada Press Brake Tooling

Need specific tooling that’s not listed? Leave your contact details, and our experts will assist you with a customized technical solution, at no additional cost.

F 16.500 (700KN/m Max)
Length	Weight
508mm	17.7KG
550mm	19.2KG

Inquiry

F 16.510 (450KN/m Max)
Length	Weight
508mm	16.8KG
550mm	18.2KG

Inquiry

F 16.520 (400KN/m Max)
Length	Weight
508mm	11.5KG
550mm	12.4KG

Inquiry

F 16.540 (1000KN/m Max)
Length	Weight
508mm	9.1KG
550mm	9.8KG

Inquiry
